Laser scanning in architecture
Urbica can support surveyors, architects or departmental managers in the production of 2D or 3D plans.
From the production of a simple façade plan to section diagrams of buildings on a Hausmannian scale, ranging through 3D plans of roof structures or structural frameworks, large-scale reception rooms or entrance lobbies accommodating the confluence of majestic stairways ... this is the brief of our team.
APPLICATIONS
- Control of structural deformation
- Elevations, section, plan view
- 3D model of building
- Complex façade plans
- Building plans
- Roofing plans
- Restitution of architectural details: mouldings, corbels, roses, etc.
- Preservation and archiving of classified and historic monuments
- Public presentation of civil engineering structures
- Dimensional survey
- Virtual tour of an edifice
back to top of page
BENEFITS
- Very high capture speeds
- Exhaustive and detailed plans
- Frequently more cost-effective than a conventional survey
- 3D view of the building
back to top of page
END PRODUCTS
- Files types: Autocad (DXF/DWG), Microstation (DGN),
Solidworks, 3DStudioMax (3ds & max), Pointools (POD/PTL) ,
and of course all the open format files like IGES, OBJ, STEP, VRML etc... - 3D models
- Structured 3D model, with attached catalog
- Accurate, high density point cloud, with a high level of detail
- Faithful restitution of complex monuments
- 2D orthographic image (façade, cut section, elevation, layouts, …)
- 2D digitized data (façade, cut section, elevation, layouts, …)
- Scan-review (Collaborative review of laser survey through panoramic images)
back to top of page
